IPC2124LB-AF28K-DL
|
|
|
Kamera
|
|
Sensor
|
1/3", 4.0 megapixel, progressive scan, CMOS
|
|
Minimum Illumination
|
Colour: 0.005 lux ( F1.6, AGC ON)
0 Lux with light
|
|
Day/Night
|
IR-cut filter with auto switch (ICR)
|
|
Shutter
|
Auto/Manual, 1 ~ 1/100000s
|
|
Adjustment Angle
|
Pan: 0° ~ 360°
|
|
|
|
WDR
|
DWDR
|
|
S/N
|
>52dB
|
|
Lens
|
|
Lens type
|
2.8mm@F1.6
|
|
|
Iris
|
Fixed
|
|
Field of View (H)
|
97.0°
|
|
|
Field of View (V)
|
52.2°
|
|
|
Field of View (D)
|
107.5°
|
|
|
DORI
|
|
DORI Distance
|
Lens (mm)
|
Detect (m)
|
Observe (m)
|
Recognize (m)
|
Identify (m)
|
|
2.8
|
63(206.7ft)
|
25.2(82.7ft)
|
12.6(41.3ft)
|
6.3(20.7ft)
|
|
|
|
|
|
|
Illuminator
|
|
IR Range
|
Up to 30m (98ft)
|
|
Warm Light Range
|
Up to 30m (98ft)
|
|
Light On/Off Control
|
Auto/Manual
|
|
Video
|
|
Video Compression
|
Ultra H.265,H.265, H.264
|
|
Frame Rate
|
Main Stream: 4MP (2560*1440), Max 25fps; 3MP (2304*1296), Max 30fps; 1080P (1920*1080), Max 30fps; 720P (1280*720), Max 30fps
Sub Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps;
|
|
H.264 code profile
|
Baseline profile, Main profile, High profile
|
|
Video Bit Rate
|
128 Kbps~6144Kbps
|
|
U-code
|
Support
|
|
OSD
|
Up to 4 OSDs
|
|
Privacy Mask
|
Up to 4 areas
|
|
ROI
|
Up to 8 areas
|
|
Video stream
|
Dual streams
|
|
|
|
White Balance
|
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
|
|
Digital noise reduction
|
2D/3D DNR
|
|
Smart Illumination
|
Support
|
|
Flip
|
Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise
|
|
Dewarping
|
N/A
|
|
HLC
|
Support
|
|
BLC
|
Support
|
|
Defog
|
Digital Defog
|
|
Events
|
|
Basic Detection
|
Motion detection, Ultra motion detection, Tampering alarm, Audio Detection
|
|
General Function
|
Watermark, IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication, HTTP Authentication
|
|
Audio
|
|
Audio Compression
|
G.711U, G.711A
|
|
Audio Bitrate
|
64 Kbps
|
|
Two-way Audio
|
N/A
|
|
Suppression
|
Support
|
|
Sampling Rate
|
8KHz
|
|
Storage
|
|
Edge Storage
|
Micro SD, up to 128 GB
|
|
Network
|
|
Protocols
|
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, Qos, SMTP, SSL/TLS, SNMP
|
|
Compatible Integration
|
ONVIF (Profile S, Profile T, Profile G),API,SDK
|
|
User/Host
|
Up to 32 users. 2 user levels: administrator and common user
|
|
Security
|
Password protection, strong password, HTTPS encryption, Export operation logs, basic and digest authentication for RTSP, digest authentication for HTTP, TLS 1.2 , WSSE and digest authentication for ONVIF
|
|
Client
|
EZStation
EZLive
EZView
|
|
Web Browser
|
Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above
|
|
Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above
|
|
Interface
|
|
Network
|
1 * RJ45 10M/100M Base-TX Ethernet
|
|
Video Output
|
N/A
|
|
Certification
|
|
EMC
|
CE-EMC (EN 55032,EN 61000-3-3,EN IEC 61000-3-2,EN 50130)
FCC (FCC 47 CFR part15 B)
|
|
Safety
|
CE LVD (EN 62368-1)
UL/CUL (UL 62368-1, CAN/CSA C22.2 No. 62368-1)
|
|
Environment
|
CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU)
|
|
Protection
|
IP67 (IEC 60529)
|
|
General
|
|
Power
|
DC12V(±25%) , PoE(IEEE 802.3af)
|
|
Power consumption: Max 2.8W
|
|
Power Interface
|
Ø 5.5mm coaxial power plug
|
|
Dimensions (L x W x H)
|
162 × 67 × 67mm (6.4” × 2.6” × 2.6”)
|
|
Weight
|
0.24kg(0.53lb)
|
|
Material
|
Metal + Plastic
|
|
Working Environment
|
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
|
|
Storage Environment
|
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
|
|
Surge protection
|
4KV
|
|
Reset button
|
N/A
|
